Scope: Nominal voltage of 3.7V lithium battery (including 18650,26650, polymer lithium battery)
Product Size: 41 * 60 * 3.4mm (Balanced version)
Product weight: 9.8g (balanced version)
Charging voltage: 12.6V – 13.6V
Continuous discharge current (upper limit): 40A (if the cooling environment is not good, please reduce the load current )
Continuous charge current (upper limit): 20A
Balanced version: Suitable for electric drill with starting current below 80A and power below 170W .(with balanced charging function)
Note 1: To successfully start, the drill requires three 15C-20C power batteries, or six 10C-15C power batteries (ordinary 18650 batteries can not start the drill!!).
Note 2: When you wire 0V, 4.2V, 8.4V, 12.6V, please do it strictly according to the wiring diagram. Do not deliberately make it short-circuit.
Note 3: When the battery is charging, the “430” resistance heating is normal, which means the balance circuit works. If the “430” resistance is also heating without charging, please check if the wrong wire is connected.
Note 4: Do not use a mix of good battery and poor battery, please make sure each battery is the same in capacity and internal resistance.
